    UN pail can making machine

    Ask Lasest Price
    Brand Name : Sunnran
    Price : $170,000.00 - $200,000.00/Pieces
    • Product Details
    • Company Profile

    UN pail can making machine

    Products Description
    Pail can making line
    UN pail can making machine
    Three types of pail can making line can be selected, ZD-T18C, ZD-T18CG, ZD-T18A. ZD-T18C pail line flanges and curls the cylinders by die . Because of the resemblance of the ZD-T18C pail line and ZD-GJ18D drum line , ZD-T18C pail line can be modified for both pail and drum making . ZD-T18CG and ZD-T18A are using flanging & curling roller to make the cylinder flanged and curled. These design can adapt to different raw material and reduce defective percentage.
    Model
    Max Speed
    Diameter range
    Height range
    Air pressure
    Power
    SR-T18CG
    35CPM
    220-330
    100-350
    ≥0.6Mpa
    APP.58Kw
    UN pail can making machine
    UN pail can making machine
    UN pail can making machine
    UN pail can making machine
    Welding line
    UN pail can making machine
    Adopts sheet upward feeding to avoid double sheet issue. Can add additional storage platform for stocking the body blanks to enable machine continuously running and enhance productivity . With new innovated frequency inverter to make perfect welding seam. Internal and external roller coating machine is quipped with automatic lacquer feeding system to enable continuous operation. After roller coating , the lever-type mechanical brush can prevent the cylinder movement hit off the can bodies. Induction oven can be designed to linear or U-shape according to client’s workshop layout.
    Automatic welder
    Wire speed
    Can diameter
    Can height
    Can material
    Power capacity
    9-24m/Min
    200-260/260-290
    180-450
    Tinplate,Ni-plate,SS
    26Kw
    Internal & external coating machine
    Coating speed
    Can diameter
    Coating width
    Power Consumption
    Power source
    10-35m/min
    52-300
    10-14
    0.6Kwh
    220V
    Induction oven
    Conveying speed
    Heater Qty.
    Power
    Cooling water
    Air source
    9-30m/min
    3 x 2m/Heater
    380V , 50Hz
    >30L/min>400Kpa/cm2<20℃
    UN pail can making machine
    UN pail can making machine
