LED curing oven for tinplate printing line
The LED curing oven is a cutting-edge technology used in the
tinplate printing line to ensure efficient and high-quality curing
of printed tinplate sheets. This advanced oven utilizes LED lights
to provide a precise and uniform curing process, resulting in
durable and vibrant prints.
One of the key advantages of the LED curing oven is its ability to
emit a specific wavelength of light that matches the absorption
spectrum of the ink. This targeted curing process ensures that the
ink is fully cured, eliminating the risk of under-cured or
over-cured areas on the tinplate sheets. As a result, manufacturers
can achieve consistent and flawless prints with excellent color
accuracy.
In addition to its precise curing capabilities, the LED curing oven
operates at a lower temperature compared to traditional curing
methods. This not only reduces energy consumption but also
minimizes the risk of heat damage to the tinplate sheets. The lower
temperature also allows for faster curing times, increasing the
overall productivity of the printing line.
Power Consumption
Total Power: 36KW (2-color LED UV)
Lamp Lifetime
1.Designed Lifetime: 10,000h
2. Warranty: either 2 years or 10,000h, up to which comes first.
3. Instant ON/OFF, no need warming up, no standby power
Lamp-on Speed
Instant ON up to 100% when sheets detected at feeder, and
instant OFF when no sheets
Heating
Cold light source with very small heat, no infrared irradiance,
low temperature rise at sheet surface
Evenness
UVLED is made up 22 independent modules with separate
controlling, quite even light irradiance.
Environment Protection
No ozone produced
Spectrum
Wavelength 365nm-395nm just like usual illuminating ray.
Floor Space
LED UV Host 2.0m. no need cooling device (chiller is put at
side near electrical cabinet) Saved 3.5m of line length.
